FAW 23m aerial work truck is equipped with FAW Tiger VR chassis and Yuchai YC4D130-33 diesel engine, delivering steady lifting capacity for municipal overhaul and outdoor high-altitude construction
This FAW 23-meter aerial work truck adopts reliable FAW Tiger VR original chassis, equipped with Yuchai YC4D130-33 four-cylinder diesel engine rated at 130 horsepower, featuring low fuel consumption, strong power output and stable running performance adapting to complex road conditions. The full hydraulic lifting system realizes flexible boom expansion and 360-degree rotating working platform, with safe load capacity and overload protection device to guarantee high-altitude construction safety. Widely used in municipal engineering, road lighting repair, building decoration, airport and factory routine maintenance. As professional FAW exporter, we provide factory-direct supply, complete export certification and after-sales service for global customers.
FAW Tiger Vh 4x2 23m Aerial Work Truck | |
Drive System | 4×2; Right hand drive |
Cabin | Tiger Vh single row flatbed cabin, with A/C |
Engine | Brand:YUCHAI Brand Model:YC4D130-33 Horsepower:130HP; |
Gear box | |
Clutch | Ф330 |
Frame | 865*216*75*6(mm) |
Wheel base (mm) | 3300mm |
Front axle | 7B9-QingTe |
Rear axle | FAW 1069 punched welded axle ; |
Tire | 7.50R16-14PR |
Diesel tank | 100L |
Others | Maintenance free battery; hydraulic brake |
Spring suspension | F3/R10+4 |
Rated load of work platform | ≤ 250 kg |
Max. working height | 23 m |
Operating range at max. operating height | 5.0 m |
Max. operating range | 9 m |
Working height at max. operating range | 13 m |
Outrigger span | Horizontal: 5600mm Vertical 4000 mm |
Fence and platform | Stainless steel fence and anti-skid platform |
PTO | Mechanical operation |
Working platform | 1400x700x1150 mm |
Boom type | Four section hexagonal working arm, synchronous telescopic |
Rotation angle | 360°full rotation |
Outrigger | Front V-type, rear H-type, Individually adjustable |
Operation type | Working platform or operated with remote control standing on the ground |
Contral system | Electro hydraulic proportional control system, realizing stepless speed regulation |
