FAW Tiger 6G 4×2 EV Cargo Box Truck

products
Specifications:

FAW Tiger 6G 4×2 RHD electric truck adopts CAM230PT52 electric motor with 93PS power output, matched with CAR4E060 air-brake electric drive rear axle at 15.596 final drive ratio and 3400mm wheelbase, outfitted withABS, ESP, AEBS, LDWS, FCW, ASR and tire pressure monitoring  to meet Australia’s strict road safety standards. The vehicle’s core power  is built around 100.07kWh liquid-cooled lithium iron phosphate battery 540.96V/185Ah, equipped with CBXB0 single cell and L185E01 assembled module, supporting European standard AC & DC dual charging plus 22kW built-in OBC charger to greatly improve charging flexibility. Its wide flat-top single-row RHD cab comes with four-point air suspension, ventilated & heated air lumbar driver seat, multifunctional steering wheel, EPS and cruise control; full comfort configurations including automatic PTC air conditioner, power windows, central locking, auto headlights with rain-triggered wiper, keyless entry and one-key start are all standard. Fitted with 195/85R16 8PR tires and 4160×2100×2100mm left-opening closed cargo box, this CBU complete electric light truck is fully optimized for Australian last-mile logistics, supermarket distribution and small-scale freight transportation

Parameter

Specification

Basic Vehicle Information


Vehicle Model

Tiger 6G Right-Hand Drive RHD Pure Electric Light Truck

Certified Gross Vehicle Weight GVW

4.495 Tons

Vehicle Category

Light Truck

Product Type

Complete Vehicle CBU

Drive Configuration

4×2

Wheelbase

3400mm

Powertrain & Battery


Motor Model

CAM230PT52

Rated Power Output

93PS

Battery Type & Capacity

CATL 100.07kWh Lithium Iron Phosphate LFP Battery

Battery Voltage & Capacity

540.96V/185Ah

Energy Storage Cell Model

CBXB0

Assembled Energy Storage Module Model

L185E01

Battery Thermal Management

Liquid Cooling & Heating

Charging Standard

EU Standard DC + AC Charging

On-Board Charger OBC

22kW

Vehicle Control Unit VCU

FAW CAN20D40553 All-in-One Controller, 3610115*** VCU

Cruising Range

487km Constant Speed Test

Chassis & Brake


Front Axle

0HE0 Yihe Manufactured

Rear Axle Assembly

CAR4E060 Air Brake High-Speed Single-Reduction Wedge Electric Drive Rear Axle

Rear Axle Ratio

15.596

Suspension

Leaf Spring 3/8+7

Brake

Air Brake , Non-autonomous Controlled Electronic Parking Brake EPB

Air Reservoir

16L+16L Aluminum Alloy Dual-Chamber Air Reservoir

Anti-lock Braking  ABS

Knorr-Bremse ABS

Tire Size

195/85R16 8PR

Wheel Rims

Aluminum Alloy Wheel Rims

Spare Tire

No Spare Tire

Frame Specification

780*180*60*4
