FAW J5K 12m³ compactor garbage truck with 4×2 chassis, E2 emission standard, and Xichai CA6DF2D-18 180HP engine delivers efficient urban waste collection. Its powerful compression system reduces transport trips by 40%, cutting operational costs while preventing secondary pollution. Ideal for municipal sanitation and waste management projects
FAW J5K 4×2 Compree Garbage Truck
Chassis & Powertrain: FAW J5K 4×2 special sanitation chassis, equipped with Xichai CA6DF2D-18 inline 6-cylinder diesel engine (180 horsepower/132kW), meeting E2 emission standards. The engine features reliable performance, low fuel consumption (≤18L/100km under standard conditions), and extended service intervals (50,000km) FAW Trucks.
Compaction System: 12 cubic meter high-strength steel sealed garbage bin with hydraulic compression mechanism (compression ratio 1:3.5), enabling efficient waste loading, compaction, and unloading. Electric-hydraulic control system with both cab and ground operation panels ensures safe and convenient operation .
Key Features: Heavy-duty frame with reinforced structure, rearview camera for enhanced safety, easy-to-clean anti-corrosion coating, and integrated sewage collection system to prevent leakage. The truck also includes manual emergency operation mode for backup in case of power failure .
Compliance: CE certified, ISO9001 quality management system approved, and designed to meet international sanitation vehicle safety standards, making it suitable for export to global markets
FAW J5K 4×2 RHD Compactor Garbage Truck Chassis | |
Drive System | 4×2 |
Cabin | FAW J5K flatbed roof cabin,Air conditioning, Air spring seats, With fairing |
Overall Dimension(mm) | 9200×2700×3250 |
Loading capacity (kg) | 12 Ton |
Engine | Brand:FAWDE Diesel 4 stroke direct injection diesel engine, 6 cylinder in-line with turbo-charging & water cooling. Model: CA6DF2D-18 Emission Standard:Euro 3 Displacement:6.56L Horse Power:180HP |
Gear box | Brand:FAW Model:CA6TBX075M |
Clutch | Ф380 |
Frame | 237*75*7+4 |
Wheel base (mm) | 4770 |
Front axle | G116-HaiTong |
Rear axle | FAW 435 Punch Welding Axle,11.5T loading capacity Main ratio=5.571 |
Specification of Compactor Garbage Box | ||
Compression box | Effective volume | 12m3 |
Box material | Q355 steel plate | |
Edge plate thickness | 4mm | |
Bottom plate thickness | 5mm | |
Compression ratio | ≥2.5 | |
Capacity of sewage tank | Front sewage tank 300L/ Rear sewage tank 500L | |
Others | Compactor garbage truck configuration: Body effective volume: 12 cubic meters; Q355 steel plate, 4mm side, 5mm bottom (high-strength special steel); Compactor effective volume: 0.8 m³; Compactor filling cycle time ≤25s; Compactor lifting time ≤15s; Maximum tipping capacity: 500kg; Tipping mechanism working time ≤10s; Control method: Automatic + Manual; Control system: CAN-BUS bus control, electromagnetic valves, Behring pneumatics, engine power control, fully automatic control, electronic control system, CAN-BUS bus control + silicone button control box; Hydraulic system pressure: 18MPa. | |
